MVE HEco 819P-190

Article: HEco 819P-190

Price:

Production: USA

Система управления TEC3000 для криохранилищ серии MVE HEco 800

Криохранилище серии MVE HEco 800 с обслуживающим персоналом

Внутреннее устройство криохранилищ серии MVE HEco 800

Description Characteristics

The MVE HEco 819P-190 cryogenic storage facility provides stable cryogenic storage of up to 19,500 1.2 / 2.0 ml cryoprobes.
The MVE HEco series is a new generation of Cryoport cryoservices. With a unique housing design, a streamlined liquid nitrogen supply system, and a vacuum metal hose for liquid nitrogen overflow, the MVE HEco 800 Series cryopreservers provide optimal liquid nitrogen consumption, making them the most efficient liquid nitrogen vapor storage cryopreservers available.

The design feature of the cryopreservation is the hinged working surfaces, which completely cover all the electronics and pipelines, ensuring reliability and safety of use.

Technical improvements in combination with the modernization of the appearance made it possible to create a cryopreservation pleasant from an aesthetic point of view and with extensive functionality. Like all MVE cryopreservers, the MVE HEco 800 series is available in three unique sizes and provides maximum sample density, durability, and high storage security.

Comes with TEC 3000 electronics and a touch screen.

Distinctive features:

LN2 flow efficiency
All electrical cables and fittings are completely hidden
Vacuum metal hose for liquid nitrogen overflow
Storage of samples in the dry phase
The temperature on the top shelf of the rack is -190°C
Lowest lifting height of the sample loading/unloading rack
Single-stage stand as standard
Two-stage stand (optional)

Spare parts warranty 2 years

Vacuum system warranty 5 years

Maximum storage capacity
Test tubes of 1.2 and 2 ml (with internal thread)	19500
Number of cryobox racks per 100 cells	12
Number of mini racks for cryoboxes for 25 cells	4
Number of shelves in the rack	15
Operational characteristics
Volume of liquid nitrogen for filling cryopreservation without storage system, calculated	446 l
Volume of liquid nitrogen for filling the cryopreservation to the platform, calculated	55 l
Cryopreservation dimensions
Internal diameter of the neck	317 mm
Usable internal height	877 mm
Inner diameter	731 mm
Total height	1465 mm
Lifting height of the cryo storage rack	1209mm
Required doorway width**	813 mm
Required doorway width for cryo storage with handles **	843 mm
Empty cryopreservation weight *	234 kg
Weight of liquid nitrogen cryopreservation*, estimated	608 kg

Cryopackage capacity	Total packages	Packages per frame	Quantity of frames
791 OS/U Medsep (25 ml)	1836	9	204
4R9951 (50 ml)	1024	8	128
4R9953 (250 ml)	520	5	104
4R9955 (500 ml)	380	5	76
DF200 (200 ml)	295	5	59

* Without a sample storage system.
** The minimum width of the doorway required to bring the vessel into the room. The area at the base may vary. Contact technical support for detailed drawings.
Complies with MDD 93/42 / EEC, the EU Medical Equipment Directive. Cryopreservation facilities are included in the UL/C-UL list.
