SC 2/1V

Article: MV-9922339

Price:

Production: USA

Description Characteristics

The MVE SC 2/1V dewar vessel provides storage of 88 1/2 мл straws , 182 1/4 мл straws and 0 vials for 8 days. Holds 1,5 liters of liquid nitrogen.

The MVE CryoShipper series is designed for the safe transport of biological samples at cryogenic (-150°C or below) temperatures. The MVE CryoShipper series uses advanced QWick refueling technology, which allows you to refuel the storage system in the vapor phase for two hours. New / warm vessels must be filled with liquid nitrogen and left for 24 hours to achieve maximum cold retention time. When the vessel is cooled for at least 24 hours, the Advanced QWick Charge technology is activated, ensuring the safe delivery of biomaterials in the vapor phase. Made of strong and lightweight aluminum, the vapor transport vessels use a hydrophobic compound that absorbs liquid nitrogen, providing a dry vapor phase without spills.
It is recommended to use MVE protective containers. These vessels can be used to send your "non-hazardous" classification samples around the world, reducing costs and helping to ensure the viability of the samples.

Distinctive features:

It is recommended to use MVE protective containers during transportation
Protective containers guarantee transport in an upright position
Low liquid nitrogen consumption
Convenient lightweight packaging
REFUELING IN TWO HOURS ( Without storage system)

Features of the advanced QWick™ refueling technology

Spare parts warranty 2 years * Vacuum system warranty 3 years

Maximum storage capacity
Number of canisters	1
The number of 1/2 ml straws 10/cane	-
The number of 1/2 ml straws on 1 level bulk	88
The number of 1/4 ml straws on 1 level bulk	182
The number of 1,2 and 2,0 ml vials 5/cane	-
The number of 1,2 and 2,0 ml vials 6/cane	-
The number of bloodbags stored 4R9953	-
Performance
Liquid nitrogen capacity, calculated	1,5 l
Static holding time	8 days
Static evaporation rate*	0,19 l/day
Unit dimensions
Inner diameter of the neck	35,0 mm
Overall height	343 mm
Outer diameter	184 mm
Canister height	127 mm
Canister diameter	31 mm
Weight empty	2,7 kg
Weight Charged vapor	3,6 kg
Weight full liquid	4,1 kg
Protective shipping container, part number	20 750 408

* Without storage system
The actual static storage rate and performance may vary depending on atmospheric conditions, sample temperature, and usage.
Complies with MDD 93/42/EEC, the EU Medical Equipment Directive.
